HYBRID ALL TERRAIN

The Baja ATZ P3 has a unique “hybrid” design between an all-terrain and mud terrain tread pattern to give the grip needed for weekend adventures and a smooth ride on paved conditions. The ATZ P3 features an extra wide footprint and tough sculptured tread blocks for great all around traction.

  • Silica-reinforced tread compound for enhanced wet performance, longevity and cut/chip resistance
  • Powerply 3-Ply sidewall construction for sidewall protection and responsive handling
  • Wide lateral and circumferential voids of mud terrain like off road traction
  • Deep aggressive shoulder SideBiters® for protection and improved off road traction
  • Scalloped shoulder lugs for improved off road traction

Sizes

15 INCH

TIRE SIZE /
EQUIV. SIZE		 LOAD
RANGE		 SIDEWALL SERVICE
DESC		 MEAS RIM
APPROVED RIMS		 MAX LOAD
MAX INFL		 O.D. IN. SECT. WIDTH IN. TREAD WIDTH IN. TREAD DEPTH 32NDS APX. WT. LBS. MATL #. PART #
31X10.50R15LT
 C BLK 109Q 8.5
7.0-9.0		 2,270 lbs @
50 psi.		 30.8 10.7 8.4 18.5 45 90000001902 55510 Buy
32X11.50R15LT
 C BLK 113Q 9.0
8.0-10.0		 2,535 lbs @
50 psi.		 31.5 11.0 9.2 18.5 50 90000001911 55521 Buy
33X12.50R15LT
 C BLK 108Q 10.0
8.5-11.0		 2,205 lbs @
35 psi.		 32.8 12.0 9.9 18.5 58 90000001912 55532 Buy

16 INCH

TIRE SIZE /
EQUIV. SIZE		 LOAD
RANGE		 SIDEWALL SERVICE
DESC		 MEAS RIM
APPROVED RIMS		 MAX LOAD
MAX INFL		 O.D. IN. SECT. WIDTH IN. TREAD WIDTH IN. TREAD DEPTH 32NDS APX. WT. LBS. MATL #. PART #
LT225/75R16
29X8.50R16		 E BLK 115Q 6.0
6.0-7.0		 2,680 lbs @
80 psi.		 29.5 8.9 7.0 18.5 44 90000022372 55699 Buy
LT245/70R16
30X9.50R16		 E BLK 118Q 7.0
6.5-7.0		 2,910 lbs @
80 psi.		 29.5 9.8 7.5 18.5 48 90000022368 55609 Buy
LT235/85R16
32X9.50R16		 E BLK 120Q 6.5
6.0-7.5		 3,042 lbs @
80 psi.		 32 9.5 7.4 18.5 51 90000022371 55629 Buy
LT265/75R16
32X10.50R16		 E BLK 123Q 7.5
7.0-8.0		 3,415 lbs @
80 psi.		 32 10.5 8.4 18.5 53 90000001913 55621 Buy
LT285/75R16
33X11.50R16		 E BLK 126Q 8.0
7.5-9.0		 3,750 lbs @
80 psi.		 32.9 11.7 9.3 18.5 56 90000001914 55631 Buy
LT305/70R16
33X12.50R16		 E BLK 124Q 9.5
8.0-9.5		 3,525 lbs @
65 psi.		 33.1 12.0 10.0 18.5 63 90000001915 55632 Buy
LT315/75R16
35X12.50R16		 E BLK 127Q 8.5
8.0-11.0		 3,860 lbs @
65 psi.		 34.5 11.9 10.0 18.5 67 90000001916 55652 Buy

17 INCH

TIRE SIZE /
EQUIV. SIZE		 LOAD
RANGE		 SIDEWALL SERVICE
DESC		 MEAS RIM
APPROVED RIMS		 MAX LOAD
MAX INFL		 O.D. IN. SECT. WIDTH IN. TREAD WIDTH IN. TREAD DEPTH 32NDS APX. WT. LBS. MATL #. PART #
LT245/70R17
31X9.50R17		 E BLK 119Q 7.0
6.5-8.0		 3,000 lbs @
80 psi.		 30.7 9.6 7.6 18.5 50 90000022367 55719 Buy
LT265/70R17
32X10.50R17		 E BLK 121Q 8.0
7.0-8.5		 3,195 lbs @
80 psi.		 31.9 10.7 8.7 18.5 54 90000001917 55721 Buy
LT285/70R17
33X11.50R17		 E BLK 121Q 8.5
7.5-9.0		 3,195 lbs @
80 psi.		 33 11.5 9.3 18.5 59 90000001918 55731 Buy
LT305/65R17
33X12.50R17		 E BLK 121Q 9.0
8.5-11.0		 3,195 lbs @
65 psi.		 32.6 12.3 10.0 18.5 63 90000001919 55732 Buy
LT295/70R17
34X12.00R17		 E BLK 121Q 8.5
7.5-10.0		 3,195 lbs @
80 psi.		 33.2 12.0 9.8 18.5 64 90000022366 55742 Buy
35X12.50R17LT
 D BLK 119Q 10.0
8.5-11.0		 3,000 lb lbs @
50 psi.		 34.4 12.7 10.0 18.5 66 90000031442 55759 Buy
LT315/70R17
35X12.50R17		 D BLK 121Q 9.5
8.0-11.0		 3,195 lbs @
50 psi.		 34.6 12.8 10.0 18.5 65 90000001940 55752 Buy
37X12.50R17LT
 D BLK 124P 10.0
8.5-11.0		 3,525 lbs @
50 psi.		 36.9 13.1 10.4 18.5 85 90000001941 55772 Buy

18 INCH

TIRE SIZE /
EQUIV. SIZE		 LOAD
RANGE		 SIDEWALL SERVICE
DESC		 MEAS RIM
APPROVED RIMS		 MAX LOAD
MAX INFL		 O.D. IN. SECT. WIDTH IN. TREAD WIDTH IN. TREAD DEPTH 32NDS APX. WT. LBS. MATL #. PART #
LT275/70R18
33X11.50R18		 E BLK 125Q 8.0
7.0-8.5		 3,640 lbs @
80 psi.		 33.1 11.1 9.0 18.5 60 90000001942 55831 Buy
LT305/60R18
33X12.50R18		 E BLK 121Q 9.0
8.5-11.0		 3,195 lbs @
65 psi.		 32.6 12.1 10.0 18.5 65 90000001943 55832 Buy
35X12.50R18LT
 D BLK 118Q 10.0
8.5-11.0		 2,910 lb lbs @
50 psi.		 34.5 12.7 10.2 18.5 68 90000031443 55859 Buy
LT305/70R18
35X12.50R18		 E BLK 126Q 9.0
8.5-10.0		 3,750 lbs @
65 psi.		 35.1 12.5 10.0 18.5 71 90000001944 55852 Buy

20 INCH

TIRE SIZE /
EQUIV. SIZE		 LOAD
RANGE		 SIDEWALL SERVICE
DESC		 MEAS RIM
APPROVED RIMS		 MAX LOAD
MAX INFL		 O.D. IN. SECT. WIDTH IN. TREAD WIDTH IN. TREAD DEPTH 32NDS APX. WT. LBS. MATL #. PART #
LT285/55R20
33X11.50R20		 E BLK 122Q 9.0
8.0-10.0		 3,305 lbs @
80 psi.		 32.6 11.7 9.3 18.5 63 90000001945 55231 Buy
LT305/55R20
33X12.50R20		 E BLK 121Q 9.5
8.5-11.0		 3,195 lbs @
65 psi.		 33.4 12.5 10.3 18.5 63 90000001946 55232 Buy
LT275/65R20
34X10.50R20		 E BLK 126Q 8.0
7.5-9.5		 3,750 lbs @
80 psi.		 34.2 11.1 9.0 18.5 58 90000001947 55240 Buy
35X12.50R20LT
 E BLK 121Q 10.0
8.5-11.0		 3,195 lbs @
65 psi.		 34.7 12.5 10.0 18.5 69 90000001948 55252 Buy
37X12.50R20LT
 E BLK 126P 10.0
8.5-11.0		 3,750 lbs @
65 psi.		 36.7 12.5 10.4 18.5 84 90000001949 55272 Buy

22 INCH

TIRE SIZE /
EQUIV. SIZE		 LOAD
RANGE		 SIDEWALL SERVICE
DESC		 MEAS RIM
APPROVED RIMS		 MAX LOAD
MAX INFL		 O.D. IN. SECT. WIDTH IN. TREAD WIDTH IN. TREAD DEPTH 32NDS APX. WT. LBS. MATL #. PART #
LT325/50R22
35X13.00R22LT		 E BLK 122Q 10.0
9.0-11.0		 3,305 lbs @
65 psi.		 35.1 12.9 11.4 18.5 78 90000026619 55253 Buy
37X13.50R22LT
 E BLK 123Q 11.0
8.5-11.0		 3,415 lbs @
65 psi.		 36.8 13.4 10.8 18.5 82 90000026770 55273 Buy

Quality + Construction

TREAD

Silica-reinforced tread for enhanced wet traction

TREAD

Wide lateral voids for severe terrain traction

TREAD

Large surface tread for all terrain handling

SIDEWALL

3-Ply Sidewall for protection and responsive handling

SIDEWALL

Scalloped shoulder lugs for off-road traction

SIDEWALL

Deep aggressive sidebiters for protection and traction

Note: All specifications are for single rear tire applications.
