Sidebiter® II

Sidebiter® II

M/T CLASSIC SERIES

The Mickey Thompson Sidebiter II is styled after the revolutionary “tread-on-the-sidewall” Mickey Thompson Sidebiter tire design. The 7-spoke design is a heavy duty performer with a black satin finish. The Sidebiter II is available in a complete range of sizes from 15x8 through 22x12.

  • All new center cap provides easy access to locking hubs
  • High load rating for strength and durability
  • Non-corrosive black plastic screw on center cap
  • Lifetime limited warranty against structural defects
  • 1-year finish warranty


Sizes

15 INCH

SIZE BOLT CIR. BACK SPACE IN. OFFSET MM HUB BORE MM. MAX. LOAD LB. APP. WT. LB. REPL. CAP* MATL #. PART #
15X8
5X4.5 3.6 -22 81.51 2,000 23 90000019900 90000019380 3058421 Buy
15X8
5X5.5 3.6 -22 86.99 2,000 23 90000019862 90000019381 3058402 Buy
15X8
6X5.5 3.6 -22 106.10 2,000 23 90000019863 90000019382 3058412 Buy
15X10
5X4.5 3.6 -48 81.51 2,000 27 90000019900 90000019383 3050421 Buy
15X10
5X5.5 3.6 -48 86.99 2,600 27 90000019862 90000019384 3050402 Buy
15X10
6X5.5 3.6 -48 106.10 2,600 27 90000019863 90000019385 3050412 Buy

16 INCH

SIZE BOLT CIR. BACK SPACE IN. OFFSET MM HUB BORE MM. MAX. LOAD LB. APP. WT. LB. REPL. CAP* MATL #. PART #
16X8
6X5.5 4.5 0 106.10 2,600 25 90000019863 90000019386 3068412 Buy
16X8
8X170 4.5 0 125.20 3,640 25 90000019865 90000019388 3068170 Buy
16X8
8X6.5 4.5 0 125.20 3,640 25 90000019864 90000019387 3068482 Buy

17 INCH

SIZE BOLT CIR. BACK SPACE IN. OFFSET MM HUB BORE MM. MAX. LOAD LB. APP. WT. LB. REPL. CAP* MATL #. PART #
17X9
5X5 4.5 -12 78.11 2,600 29 90000019900 90000019389 3079431 Buy
17X9
6X135 5.0 0 86.99 2,600 29 90000019863 90000019401 3079462 Buy
17X9
6X5.5 5.0 0 106.10 2,600 29 90000019863 90000019402 3079412 Buy
17X9
8X170 5.0 0 125.20 3,640 29 90000019865 90000019404 3079170 Buy
17X9
8X6.5 5.0 0 125.20 3,640 29 90000019864 90000019403 3079482 Buy

20 INCH

SIZE BOLT CIR. BACK SPACE IN. OFFSET MM HUB BORE MM. MAX. LOAD LB. APP. WT. LB. REPL. CAP* MATL #. PART #
20X9
5X5.5 5.0 0 86.99 2,600 37 90000019862 90000019339 3029402 Buy
20X9
6X135 5.0 0 86.99 3,250 37 90000019863 90000019420 3029462 Buy
20X9
6X5.5 5.0 0 106.10 3,250 37 90000019863 90000019421 3029412 Buy
20X9
8X170 5.0 0 125.20 3,640 37 90000019865 90000019423 3029170 Buy
20X9
8X6.5 5.0 0 125.20 3,640 37 90000019864 90000019422 3029482 Buy
20X12
6X135/6X5.50 4.8 -44 106.10 2,600 42 90000030414 90000030368 3022163 Buy
20X12
8X170 4.8 -44 125.22 3,640 43 90000019864 90000030410 3022170 Buy
20X12
8X180 5.2 -32 124.31 3,640 43 90000019864 90000030411 3022180 Buy
20X12
8X6.50 4.8 -44 125.22 3,640 43 90000019864 90000030369 3022482 Buy

22 INCH

SIZE BOLT CIR. BACK SPACE IN. OFFSET MM HUB BORE MM. MAX. LOAD LB. APP. WT. LB. REPL. CAP* MATL #. PART #
22X10
8X170 5.0 -12 125.22 3,640 45 90000019864 90000030413 3220170 Buy
22X10
8X6.50 5.0 -12 125.22 3,640 45 90000019864 90000030412 3220482 Buy
22X12
6X135/6X5.5 4.8 -44 106.10 2,600 48 90000030414 90000030364 3222163 Buy
22X12
8X170 4.8 -44 125.22 3.640 51 90000019864 90000030366 3222170 Buy
22X12
8X180 5.2 -32 124.31 3.640 50 90000019864 90000030367 3222180 Buy
22X12
8X6.5 4.8 -44 125.22 3.640 51 90000019864 90000030365 3222482 Buy

IMPORTANT WHEEL FITMENT NOTES

All Mickey Thompson Classic Series, SideBiter®, and M/T Metal Series wheels require (60-Degree) Bulge Acorn (Cone Bulge) Seat Lug Nuts. Mickey Thompson recommends Duplex Bulge Acorn Lug Nuts on vehicles of GVWR of 6,500 lbs. or greater.

All Deegan 38 Series wheels use 60 Degree Conical Bulge Seat lugs but will also accept E/T Style lug nuts which provide a lug-centric installation.

For All 6x5.5 Bolt Circle Wheels: Hub Centering Ring included for late Model Chevrolet/GMC applications.

Center caps are not available for certain applications including 1997 & earlier Ford 3/4 & 1-ton pickups, 2002 & earlier Dodge/Ram 3/4 & 1-ton pickups, 1986 & earlier Jeep, CJ models & earlier Toyota Land Cruiser models.

Open caps are available for 5, 6 and 8 lug Classic Series wheels, separately.

NOTE: All dual drill wheels in the MT METAL line are cover-style caps—no exposed lugs.
