A PROVEN DRAG STRIP WINNER

A Proven Drag Strip Winner
Real world research and development give M/T® slicks the edge over competitive brands. Engineered for maximum traction and consistent ET’s with superior construction and compounding for nearly every drag race application.

  • Multiple compounds and sizes
  • Compounded for maximum traction
  • Requires little or no burnout
  • Engineered for consistent performance

SEE DRAG TIRE FOOTNOTES BELOW TABLE FOR IMPORTANT INFORMATION

Sizes

13 INCH

TIRE SIZE MEAS RIM WIDTH O.D. IN. SECT. WIDTH IN. TREAD WIDTH IN. CIRC. COMPOUND Suggested Tube APX. WT. LBS. MATL #. PART #
24.5/9.0-13 7.0 24.5 10.9 8.8 77.0 X8 248923 16 90000028340 30161

15 INCH

TIRE SIZE MEAS RIM WIDTH O.D. IN. SECT. WIDTH IN. TREAD WIDTH IN. CIRC. COMPOUND Suggested Tube APX. WT. LBS. MATL #. PART #
14.5/32.0-15 14.0 33 17.4 14.5 104.0 L8 250998 38 90000000880 30751
24.5/8.0-15 8.0 24.5 9.6 7.7 77.0 L8 248923 17 90000000831 3015
26.0/10.0-15 10.0 26 11.6 9.6 82.0 L8 248923 22 90000000843 3053
26.0/10.0-15S* 10.0 26.5 11.5 9.8 84.0 M5 248923 24 90000000846 3053S
26.0/8.5-15 8.0 25.9 9.9 8.1 82.0 L8 248923 19 90000000842 3052
28.0/10.5-15 10.0 28.1 12.5 10.0 89.0 M5 248923 23 90000000848 3055
28.0/10.5-15 10.0 28.1 12.4 10.0 88.0 L4 248923 24 90000099256 30554
28.0/10.5-15 10.0 28.1 12.5 10.0 88.0 L8 248923 24 90000100482 30558
28.0/10.5-15S* 10.0 28.1 12.5 10.0 89.0 M5 248923 24 90000000851 3055S
28.0/10.5-15S* 10.0 28.1 12.4 10.0 88.0 L8 248923 24 90000100483 30559
28.0/10.5-15W 10.0 28.1 13.1 10.9 88.0 M5 250997 26 90000000852 3055W
28.0/10.5-15W* 10.0 28.1 13.1 10.9 89.0 M5 250997 27 90000001551 30551
28.0/9.0-15 8.0 27.3 10.8 8.6 86.0 L8 248923 22 90000000847 3054
28.0/9.0-15 8.0 27.3 10.8 8.6 86.0 M5 248923 22 90000022010 3054ST
29.5/10.5-15 10.0 29.9 13.1 10.2 94.0 M5 250997 25 90000000858 3062
29.5/10.5-15S* 10.0 29.9 13.2 10.2 94.0 M5 250997 27 90000000859 3062S
29.5/10.5-15W* 10.0 29.6 13.6 11.2 93.0 M5 250997 30 90000000860 3062W
29.5/13.5-15 12.0 30.2 16.0 13.1 95.0 M5 250997 29 90000000863 3065
29.5/9.0-15ST 8.0 29.3 11.4 8.9 92.0 M5 248923 22 90000000855 3056ST
31.0/10.5-15W* 10.0 31.3 14.5 10.8 99.0 M5 250997 33 90000000869 3068W
31.0/13.0-15 12.0 31 15.7 13.0 98.0 M5 250998 32 90000000871 3072
31.25/12.2-15W 12.0 31.5 15.8 13.2 99.0 L8 250998 29 90000000874 3073W
32.0/14.0-15 14.0 31.8 17.2 14.2 100.0 L8 250998 33 90000000875 3074
32.0/14.0-15S* 14.0 32.2 17.1 14.2 102.0 L8 250998 35 90000000877 3074S
32.0/14.0-15ST* 14.0 32.2 17.1 14.2 102.0 M5 250998 36 90000000878 3074ST
32.0/16.0-15S* 15.0 32 18.5 15.8 101.0 X8 250998 42 90000022013 30771
33.0/10.5-15W* 10.0 32.9 14.5 11.2 104.0 M5 250998 33 90000000870 3069W
33.0/15.0-15S* 14.0 33.6 18.1 14.8 106.0 X8 250998 37 90000028341 3080
33.0/16.5-15S* 15.0 33.5 20.0 16.7 106.0 L8 250998 41 90000000888 3084S

16 INCH

TIRE SIZE MEAS RIM WIDTH O.D. IN. SECT. WIDTH IN. TREAD WIDTH IN. CIRC. COMPOUND Suggested Tube APX. WT. LBS. MATL #. PART #
33.0/10.5-16W 15.0 33 16.8 11.3 104.0 M5 250998 34 90000000893 3169W
33.5/16.5-16*† 16.0 33.7 20.8 16.5 106.0 X8 250998 41 90000001574 3183
34.0/13.5-16W* 16.0 34.5 18.3 14.0 109.0 X5 - 39 90000001562 3190W
34.0/13.5-16W* 16.0 34.5 18.3 14.0 109.0 X8 - 39 90000021546 3191W
35.0/15.0-16* 16.0 35.2 18.6 14.5 111.0 X5 - 41 90000001930 3195
35.0/15.0-16* 16.0 35.2 18.6 14.5 111.0 L6 - 41 90000036981 3197

Quality + Construction

TREAD

Multiple Compounds
Consistent Performance

SIDEWALL

Little/No Burnout
Superior Construction

*Stiff Sidewall
† High Growth Tire

ACCEPTABLE PRACTICE (EXCEPT ET STREET R, ET STREET R BIAS AND ET STREET S/S) FOR RIM WIDTH IS TREAD WIDTH PLUS OR MINUS ONE INCH.

WARNING: DO NOT USE ON DYNO.

IMPORTANT: ALL BIAS DRAG DRIVE TIRES MUST BE MATCHED TO BE WITHIN 1/2 INCH ROLL OUT.

NEVER USE RIM SCREWS ON RADIAL DRAG TIRES!

MICKEY THOMPSON COMPOUND SELECTION CHART

MEDIUM SOFT
X5 M5 L6 R2 R1 X8 L8 L7 L2
To identify the compound of your current M/T® ET Drag tires look at the serial number on the sidewall of the tire.
EXAMPLE: CY1J M5 FJ2620

CONSTRUCTION

ST ...... Suggested for manual transmissions (medium compound)
W ...... Extra tread width (please note actual tread and section width on spec sheet)
S ...... Stiff sidewall construction aids in quicker reaction time due to less tire distortion. Also good in high horsepower applications and for heavy cars (Over 3,000 lbs)
R ...... Radial Construction

COMPOUNDS

L2 ...... For Jr. Dragsters
L6 ...... Good for High Horsepower - Boosted Applications
L7 ...... For Motorcycles
L8 ...... Good Compound for General Use
M5 ...... Good Compound for General Use
R1 ...... Special Compound for ET Drag Radial
R2 ...... Special Compound for ET Street S/S, ET Street R & ET Street Radial Pro
X5 ...... Cooler running version of M5
X8 ...... Cooler running version of L8
